Product Description
DESCRIPTION:
Firesafe design and NACE versions available.
| Body Type | Flanged RF |
| Body | CS, SS |
| Ball | F316 |
| Stem | 316 SS |
| Seat | PTFE, RTFE, Ultra, PEEK |
| Size Range | 1” to 4” (DN25 to 100) |
| Pressure Rating | Series 75 – Class 150
Series 76 – Class 300 |
| Design Standard | API 608, ASME B16.34 |
| Testing Standard | API 598, ISO 5208 |
FEATURES
- Solid, one-piece ball
- Top plate drilled to ISO 5211 bolt circle dimensions
- Contoured seat design with no seat extrusion
- Fully adjustable packing gland with actuator mounted
- Live loaded graphite stem packing
- Robust stem provides real blowout proof design
- Anti-static device between ball-to-stem and stem to-body connection
- Self relieving seats as standard
